Amplitude-Shift Keying, Frequency-Shift Keying, and Phase-Shift Keying

Amplitude-Shift Keying, Frequency-Shift Keying, and Phase-Shift Keying

  • 2023-04-19

Digital Modulation Schemes

Amplitude-shift keying (ASK), frequency-shift keying (FSK), and phase-shift keying (PSK) are digital modulation schemes.

 Amplitude-Shift Keying

ASK refers to a type of amplitude modulation that assigns bit values to discrete amplitude levels. The carrier signal is then modulated among the members of a set of discrete values to transmit information.

FSK refers to a type of frequency modulation that assigns bit values to discrete frequency levels. FSK is divided into noncoherent and coherent forms. In noncoherent forms of FSK, the instantaneous frequency shifts between two discrete values termed the "mark" and "space" frequencies. In coherent forms of FSK, there is no phase discontinuity in the output signal. FSK modulation formats generate modulated waveforms that are strictly real values, and thus tend not to share common features with quadrature modulation schemes.

PSK in a digital transmission refers to a type of angle modulation in which the phase of the carrier is discretely varied—either in relation to a reference phase or to the phase of the immediately preceding signal element—to represent data being transmitted. For example, when encoding bits, the phase shift could be 0 degree for encoding a "0," and 180 degrees for encoding a "1," or the phase shift could be –90 degrees for "0" and +90 degrees for a "1," thus making the representations for "0" and "1" a total of 180 degrees apart. Some PSK systems are designed so that the carrier can assume only two different phase angles, each change of phase carries one bit of information, that is, the bit rate equals the modulation rate. If the number of recognizable phase angles is increased to four, then 2 bits of information can be encoded into each signal element; likewise, eight phase angles can encode 3 bits in each signal element.
